Description
Built for maximum durability in extreme industrial environments, the Yale D85 Pul-lift Ratchet Lever Hoist delivers exceptional pulling and lifting performance. Designed with a robust white malleable cast-iron housing, lever handle, and bottom block, this high-tensile lever hoist excels at resisting heavy tension and handling tough daily operations.
Inside the unit, a precision-machined graphite cast-iron load sheave features custom-fitted chain pockets. This engineered design guarantees smooth chain movement, precise load control, and minimal wear over extended use.
Key Technical Specifications
-
Lifting Capacities: Available in 5 distinct models ranging from 750 kg up to 10,000 kg (10 Tonnes).
-
Standard Height of Lift (HOL): 1.5 metres (custom longer chain lengths available upon request).
-
Construction Materials: High-tensile malleable cast iron housing & graphite cast-iron sheave.
-
Suitable Applications: Heavy machinery positioning, pipe setting, load securing, structural alignment, and rigging.
Optional Upgrades & Safety Enhancements
To tailor the Yale D85 to your specific operational needs, several safety features can be retrofitted:
-
Slipping Clutch Overload Protection: Prevents damaging equipment or risking operator safety when handling loads of unknown weights.
-
Yale YKST Adjustable Chain End Stops: Provides a crucial secondary mechanical safeguard to hold the chain securely in the event of a brake issue.
Typical Industry Applications
Thanks to its rugged, impact-resistant frame, the Yale D85 lever hoist is a trusted standard across demanding industrial sectors, including:
-
Mining & Tunneling
-
Construction & Structural Steel Erection
-
Shipbuilding & Marine Engineering
-
Plant Maintenance & Fabrication
-
Utility & Pipeline Installation
