Winchmax WinchesDescription
Premium Orange Series | Genuine Dyneema® Rope | Complete Control System
Engineered for uncompromising reliability in the most demanding environments, this 15,000lb (6,804kg) hydraulic winch is the definitive choice for heavy-duty recovery. Whether it’s for 7.5-tonne recovery vehicles, industrial plant trailers, or intensive agricultural use, the “Original Orange” delivers professional-grade hydraulic power.
This package includes a comprehensive 12v wired and wireless control suite, along with all necessary hydraulic hoses and connectors for a seamless installation.
Key Performance Features
-
Massive Pulling Power: A genuine 6,804kg (15,000lb) straight-line pull capacity driven by a high-torque hydraulic motor.
-
Armoured Construction: The outer casing is precision-machined from billet steel, offering superior impact resistance compared to standard cast alternatives.
-
Advanced Drivetrain: Features a rugged three-stage planetary gearbox with hardened steel internals for smooth, reliable power transfer.
-
Dyneema® Synthetic Line: Pre-fitted with 25m of 12mm authentic Dyneema rope—offering incredible strength with minimal weight and enhanced safety.
-
Precision Control: Equipped with a 12V CETOP 3 (NG6) solenoid-operated directional valve for responsive “power-in” and “power-out” functionality.
Comprehensive Specifications
| Component | Detail |
| Rope & Hook | 25m x 12mm Dyneema with orange competition safety hook and hand saver. |
| Fairlead | CNC-milled aluminium hawse fairlead with laser-etched branding. |
| Braking & Clutch | Sliding ring gear free-wheel clutch for rapid line payout. |
| Wired Control | Heavy-duty “big grip” handheld remote with a 4.5m wander lead. |
| Hydraulics | 4x 1.25m hose assemblies with 18×1.5mm threaded connectors. |
| Build Quality | CE Certified; manufactured to ISO9001 standards. |
| Weight | Heavy-duty construction with a total gross weight of 55kg. |
