Novawinch WinchesDescription
The Novawinch TORO22000 is a powerhouse of engineering, specifically developed for heavy-duty commercial recovery and industrial plant applications. Delivering a massive 22,000lb (9,979kg) of pulling force, this hydraulic winch is the go-to choice for professional operators who require unyielding power in a compact, chassis-mountable frame.
Built to withstand the rigours of daily commercial use, the TORO22000 is typically installed on recovery trucks, flat-bed transporters, and heavy machinery trailers.
Engineered for Compact Power
While some high-capacity winches are bulky and difficult to fit, the TORO series is designed with a streamlined footprint. This allows for easier integration into modern vehicle chassis where space is at a premium, without compromising on the 10-tonne pulling capacity required for serious recovery tasks.
Technical Performance & Hydraulics
The TORO22000 thrives on efficiency. To achieve its peak line speed of 7.0m/min, it utilizes a recommended oil flow of 75 l/min.
-
Working Pressure: 2,393 psi (16.5 MPa)
-
Gear Ratio: 22.67:1 for smooth, high-torque delivery.
-
Clutch System: Features a pneumatic clutch (operating at 1–8 bar) for effortless freespooling.
-
Protection: We recommend an independent oil supply system equipped with a relief valve to ensure the longevity of the motor and internal components.
Heavy-Duty Rigging & Capacity
Out of the box, the TORO22000 is equipped for immediate professional deployment. It comes standard with a high-tensile 16mm steel wire rope and a heavy-duty roller fairlead to reduce friction and wear during angled pulls.
Pro Tip: Remember that pulling power varies by rope layer. While the first layer provides the full 22,000lb (9,979kg), the fourth layer provides approximately 14,170lb (6,427kg) at a faster line speed of 36 fpm.
