Name: Novawinch HEN45000 Long Drum: The Titan of Heavy Recovery
Brand: Novawinch Winches
SKU: NW-HEN45000L
Availability: InStock

Novawinch HEN45000 Long Drum: The Titan of Heavy Recovery

£6,454.86 (ex. VAT) - £7,745.83 (inc. VAT)

The Novawinch HEN45000L sits at the absolute pinnacle of the HEN MAX series. This EN-rated hydraulic winch is engineered specifically for heavy-duty recovery rotators and large-scale mining operations where failure is not an option. Featuring the Long Drum configuration, this model provides a massive 58m (190.3 ft) rope capacity, ensuring you have the reach required for the most demanding recoveries.

SKU: NW-HEN45000L Categories: All Winches, EN Series, Hydraulic winches, Novawinch Hydraulic Winches, Novawinch Winches Brand:

Novawinch Winches
When it comes to recovery, utility, and industrial-grade pulling power, Novawinch stands in a league of its own. As a cornerstone of the WinchesUK lineup, Novawinch represents the perfect intersection of heavy-duty engineering and innovative technology.

Description

Equipped with a pneumatic clutch as standard and boasting IP67-rated protection, the HEN45000 is built to perform in the harshest environments on Earth.

Unmatched 20-Tonne Industrial Performance

When the job requires sheer force, the HEN45000 delivers. With a first-layer pulling capacity of 20,412kg (45,000lb), it is designed to move the heaviest industrial loads with precision.

Flow & Speed: Achieves a line speed of 3.8 m/min (12.5 fpm) at an 85 l/min oil flow.
Mechanical Advantage: Utilizes a 30.4:1 gear ratio for smooth, high-torque delivery.
Precision Pressure: Operates at a working pressure of 17 MPa (2,465 psi).

The Long Drum & Air-Control Advantage

The extended drum isn’t just about extra rope; it’s about versatility. Storing up to 58m of 22mm wire rope across four layers, this winch is the ideal choice for deep-ravine extractions or long-distance industrial pulls.

For maximum operator efficiency, the integrated pneumatic clutch (operating at 1–8 bar) allows for seamless engagement directly from the vehicle cab, increasing safety by keeping the operator away from the winch during setup.

Heavy-Duty Engineering Specifications

The HEN45000 is constructed using premium materials to ensure structural integrity under extreme stress:

Structural Strength: Features oversized cast steel drum supports and a high-grade carbon steel tie bar.
Durability: Hardened planetary gears designed for a long service life in industrial cycles.
Reliability: GV-12 threads ensure leak-resistant hydraulic connections, while the multi-disc brake system provides total load control.

Please Note: This unit requires an external hydraulic power source and a vehicle air system for clutch operation. We recommend an independent oil supply fitted with a relief valve for optimal performance.

Specifications

First Layer Line Pull:	45,000 lb (20,412 kg)
First Layer Line Speed:	12.5 fpm (3.8 m/min)
Working Pressure Diff.:	2,465 psi (17 MPa)
Oil Flow Supply:	85 l/min (recommended range 40–90 l/min)
Gear Ratio:	30.4:1
Wire Rope Diameter:	22 mm (7/8")
Rope Layers:	4
Wire Rope Capacity:	190.3 ft (58 m)
Pneumatic Clutch – Air Pressure Range:	1–8 bar
Ventilation Volume:	1 L/min
Net Weight (Excl. Rope):	650.5 lb (295 kg)

Performance by layer
Layer	Rated line pull	Line speed	Wire rope capacity
1	45,000 lb (20,412 kg)	12.5 fpm (3.8 m/min)	37 ft (11.3 m)
2	38,571 lb (17,496 kg)	14.8 fpm (4.5 m/min)	82 ft (25 m)
3	33,750 lb (15,309 kg)	17.1 fpm (5.2 m/min)	134 ft (41 m)
4	30,000 lb (13,608 kg)	19.4 fpm (5.9 m/min)	190.3 ft (58 m)
