The Novawinch HEN30000 stands as the heavyweight titan of the HEN MAX series. Engineered for the most demanding sectors—including military logistics, mining, and heavy-duty recovery rotators—this 30,000lb (13,608kg) hydraulic winch delivers uncompromising EN-rated performance. Featuring a pneumatic clutch for seamless remote operation, it is the definitive choice for professionals who require safety and strength in equal measure.
Elite Industrial Strength
The HEN30000 is purpose-built for high-stakes environments where equipment failure isn’t an option.
-
Capacity: 13,608kg (30,000lb) first-layer line pull.
-
Efficiency: Achieves a line speed of 4.6 m/min (15.1 fpm) at a 70 l/min oil flow.
-
Precision: Features a 30.39:1 gear ratio and operates at a working pressure of 2,465 psi.
Pneumatic Control & Operator Safety
Equipped with an air-actuated clutch, the HEN30000 integrates perfectly with vehicles featuring onboard air systems (1–8 bar). This allows operators to engage or disengage the winch directly from the cab or control station, significantly reducing risk by keeping personnel clear of the drum during spooling.
Military-Grade Durability
Designed to survive the harshest environments on Earth, the HEN30000 features:
-
IP67 Weatherproofing: Fully sealed against dust, grit, and high-pressure water ingress.
-
Rugged Construction: Hardened steel planetary gears, oversized casting drum supports, and a carbon steel tie bar.
-
Advanced Braking: A reliable multi-disc brake system ensures load holding under maximum tension.
Rope Capacity & Layered Performance
The drum is optimized for 18mm (3/4″) wire rope, providing a total capacity of 52m (170.6 ft) across five layers. Note that pulling power and speed scale across these layers—please refer to the specifications table for detailed layer-by-layer metrics (e.g., Layer 5 offers 17,728lb of pull at 24.3 fpm).
