Warrior WinchesDescription
Warrior Hoist 400kg (900lbs) – High-Performance Lifting Solution (24V)
This next generation 400kg (900 lbs) hoist features a high-power 3.9hp motor, allowing you to get work done with ease.
Designed for a long-life, the HD waterproof contactors and full-steel planetary gearing ensure rust-free running. The high-quality gear system also ensures this is one of the quietest and smoothest hoists on the market!
Allowing for safe cool-down breaks, the full load brake can easily hold the full 400kg load for secure pauses. While the included mount plate makes getting up and running a breeze with simple installation.
Standard Features:
- Line Capacity: 408kg (900lb)
- Rope: 10m of 6mm Steel Cable with Clevis Hook
- Motor: Permanent Magnet – Powers In and Out
- Gearbox: Full Steel Planetary Gearing
Accessories:
- Wired Hand Control: Hand control with Emergency Stop
- Wireless Control: Available as an optional extra
- Mounting Plate: Included
- Fairlead: Not Included
- Mounting Bolts: Included for standard installationsAlso Includes:
- Heavy Duty Battery Cables (May need extending dependent on application)
- Instruction Manual
Other Information: - Dimensions: 378mm L x 126mm D x 200mm H
- Mounting Bolt Pattern: 129mm x 96mm
- Approx. Shipping Weight: 13kg
- Line Pull – No Load: 3.8 m/min (15 Amps)
- Line Pull – Full Load: 3.4 m/min (28 Amps)
Important Application Note
The Winch Hoists are designed to supplement a lifting solution, offering heavy-duty pulling and secondary vertical lift assistance. For dedicated, primary lifting applications, please view our range of electric or scaffold hoists.
Disclaimer: Whilst every effort has been made to ensure accuracy of information relating to this product, in the interest of technical improvement this specification may be altered without notice.
