Gebuwin Worm Gear Winch – WW250 capacity 250KG
The Gebuwin worm gear hand winch has a transmission that consists of a worm shaft and wheel.
This hand winch is very safe due to the natural braking effect of the worm gear transmission in combination with the load pressure brake. In addition, the winch is easy to use, can be mounted in various ways and has a cable storage up to 120 meters.
Technical specifications
| Capacity 1st layer | 250 kg (551 lb) |
|---|---|
| Capacity 4th layer | 179 kg (395 lb) |
| Capacity top layer | 92 kg (203 lb) |
| Rope diameter-Ø | 4 mm (0.16 in) |
| MBL of cable | 9 kN |
| Rope storage 1st layer | 3,6 meter (12 ft) |
| Rope storage 4th layer | 18,7 meter (61 ft) |
| Rope storage top layer | 104 meter (341 ft) |
| Lifting speed | 1 m/min (3 ft/min) |
| Crank effort at full load | 5 kg (11 lb) |
| Weight (without rope) | 10 kg (22 lb) |
| Article number | 77281100 |
| Type name | WW250 |
THE BELOW OPTIONS ARE ALSO AVAILABLE – PRICE ON REQUEST
2L – 2 layers of paint in compliance with DIN/ISO 12944, C3M
GD – Grooved drum
PR – Pressure rolLer
FM – Floor mounting holes
FS – Free-spooling device for pulling applications. To disengage the drum
FSB – Free-spooling device with additional friction brake for controlled cable unwinding
