Novawinch 9500lb/4309kg 12V Electric Winch

Novawinch 9,500lb 12V Electric Winch with Wire Rope & Remote

£427.00 (ex. VAT) - £512.40 (inc. VAT)

A 9,500lb 12V electric winch with steel wire rope and wired remote for 4x4s, recovery trucks and flat-bed trailers. IP68 waterproof sealing, double disk brake, aluminium housing and UV-resistant finish. 12 month warranty.

SKU: NW-PRO9500-12 Categories: , , , , Brand: nova-logoNovawinch Winches
When it comes to recovery, utility, and industrial-grade pulling power, Novawinch stands in a league of its own. As a cornerstone of the WinchesUK lineup, Novawinch represents the perfect intersection of heavy-duty engineering and innovative technology.

Description

The Novawinch PRO9500 is a 12V 9,500lb electric winch with steel wire rope and waterproof wired remote from the PRO PLUS series. Built for 4×4 off-road recovery, recovery trucks and flat-bed trailers, it combines strong pulling capacity, IP68 waterproof sealing, a double disk brake and durable construction. 12 month warranty.

12V 9,500lb Electric Winch for 4×4, Recovery & Trailers

The PRO9500 is a 12V 9,500lb electric winch designed for 4×4 recovery, recovery trucks and flat-bed trailer use. With 4,309kg rated line pull and a 12V electric motor (6.0 hp / 4.4 kW), it delivers the power and control needed for tough recovery and load handling in demanding conditions.

Steel Wire Rope for Robust Pulling

This model is supplied with 3/8″ x 85.3′ (9.5mm x 26m) steel wire rope for durable, wear-resistant pulling. The braking system helps isolate drum heat to protect the steel rope and extend component life, so you get reliable performance in heavy-duty use on 4x4s, recovery trucks and trailers.

Double Disk Brake & Automatic Load Holding

The double disk brake gives precise control during payout and retrieval and helps improve safety in challenging situations. Combined with automatic load holding in the gearbox, the PRO9500 is built for controlled, dependable operation under load.

IP68 Waterproof & Durable Construction

With an IP68 waterproof rating, the motor and gearbox are protected from dust and moisture. The aluminium die-cast housing with stainless steel fasteners and UV-resistant powder coat help the winch stand up to harsh weather and outdoor use.

Key Features

  • 9,500lb (4,309kg) rated line pull for 4×4, recovery trucks and trailers
  • 12V electric winch with 6.0 hp (4.4 kW) series-wound motor
  • Steel wire rope 3/8″ x 85.3′ (9.5mm x 26m)
  • Double disk brake for precise control and improved safety
  • IP68 waterproof seals for motor and gearbox
  • Aluminium housing with stainless steel fasteners
  • UV-resistant powder coat for protection against the elements
  • Waterproof rubber remote with metal plug, 12.7′ (3.9m) cord

Please note: Suitable for 12V systems. Ensure correct mounting and wiring for your vehicle or equipment. 12 month warranty and technical support.

Specifications

Rated Line Pull: 9,500lb (4,309kg) single line
Voltage: 12V DC
IP Rating: IP68 waterproof seals
Motor: 6.0 hp (4.4 kW) series wound
Gear Train: 2-stage spur, 2-stage planetary
Gear Ratio: 171:1
Clutch: Rotating ring gear, 90° turn lever
Braking Action: Automatic in gearbox
Drum Size: 2.48" x 8.74" (63mm x 222mm)
Handheld Control: Waterproof rubber remote with metal plug, 12.7' (3.9m) cord
Rope Size: 3/8" x 85.3' (9.5mm x 26m) steel wire rope
Winch Dimension: 23.93" L x 7.08" W x 9.37" H (608mm L x 180mm W x 238mm H)
Mounting Bolt Pattern: 10" x 4.5" (254mm x 114mm)
Net Weight: 98.1lb (44.5kg)
Performance (12V)
Line pull Line speed Motor current
0 lb (0 kg) 52.5 FPM (16 m/min) 50 A
9,500 lb (4,309 kg) 4.3 FPM (1.3 m/min) 360 A

Whats in the Box?

  • 1 x PRO9500 winch with control box
  • 1 x Wired remote
  • 1 x Roller fairlead
  • 1 x Set of high tensile fixing bolt screws
  • 1 x 1/4" Grade 70 forged clevis hook with safety catch
  • 1 x Set of high tensile fixing bolt screws
  • 3 x Connecting cables

Video

Downloads

Novawinch_catalog_2024
