20,000lb (9072kg) Original Orange Hydraulic Winch, Steel Rope, full Control System
Includes full 12v wired/wireless control system, pipes and connectors

Ideal for recovery trucks & trailers 7.5T+, industrial, commercial & agricultural

Features

• 20,000lb (9,072kg) straight-line pull hydraulic winch (12v controls)
• Ultra-tough three-stage gearbox with hardened steel gears.
• Casing machined from billet steel for maximum impact protection.
• 25m x 14mm galvanized steel wire rope.
• Through-drum rope attachment with grub screw clamp for maximum security.
• 1/2 Inch grade 70 forged clevis hook with safety catch, zinc plated for corrosion resistance and hand saver.
• Tough four roller fairlead with zinc plated rollers.
• Sliding ring gear free-wheel clutch.
• 12V electrically operated CETOP 3 (NG6) solenoid operated directional valve control.
• Compatible with the full WINCHMAX range of wireless remote controls.
• Big grip controller for power in/out with extra-long 4.5m wander lead.
• Wander lead wiring harness and socket for connection to the solenoid valve.
• Hydraulic hose assemblies 1.25m long (x4) fitted with 18 x 1.5mm threaded fittings.
• High tensile fixing bolt kit.
• Heavy duty & built to last – gross weight 70kg.
• CE certified & built to ISO9001 quality management system requirements.

24v control system available on request

Industry-leading lifetime warranty on mechanical components & 3yrs warranty on electrical.
