Winchmax WinchesDescription
| Single Line Rated Pull | 20,000lb (9,072kg) |
| Motor | Hydraulic |
| Control | NOT SUPPLIED |
| Gear Train | 3 Stage Planetary |
| Gear Reduction Ratio | 32:1 |
| Clutch | Sliding Ring Gear |
| Braking Action | Automatic |
| Drum Size | Diameter 88mm length 222mm |
| Drum Finish | Black, painted. |
| Cable | 25m x 13mm Dyneema SK75 Synthetic Rope |
| Hook | Orange Competition Hook with Safety Catch |
| Fairlead | Aluminium Hawse Fairlead |
| Flow | 50-60 L/min |
| Pressure | 10.8Mpa (108 Bar) |
| Winch Finish | Original Orange powder coated |
| Weight (GW) | 48kg (105lb) |
| Overall Dimensions (LxWxH) | 548 x 196 x 249mm |
| Mounting Bolt Pattern | 10.00” ±0.015″ x 4.50” ±0.010″ (254 x 114.3mm) |
| No Load Line Speed | 6.5m/min (21.3 ft/min) |
| Layer Rated | Line pull (lb) | Pull per layer (kg) | Line speed (m/min) |
| 1 | 20,000 | 9,072 | 4.24 |
| 2 | 17,860 | 8,118 | 4.75 |
| 3 | 16,130 | 7,332 | 5.26 |
| 4 | 14,710 | 6,686 | 5.77 |
