20,000lb (9072kg) Original Orange Hydraulic Winch with Dyneema Rope, 24V Control System
Includes full 24v wired control system, pipes and connectors

Ideal for recovery trucks & trailers 7.5T+, industrial, commercial & agricultural

Features

• 20,000lb (9,072kg) straight line pull.
• Tough three-stage planetary gearbox with hardened steel gears.
• Motor and gearbox casing machined from billet steel for maximum impact protection.
• Sliding ring gear free-wheel clutch.
• 24V electrically operated CETOP 3 (NG6) solenoid operated directional valve control.
• Big grip controller for power in/out with extra-long 4.5m wander lead.
• Compatible with the WINCHMAX range of wireless remote controls.
• 25m x 13mm genuine Dyneema synthetic rope with drum terminal and thimble eye anchorage for the hook.
• Aluminium hawse fairlead. Precision CNC milled with laser-etched WINCHMAX branding.
• Hydraulic hose assemblies 1.25m long (x4) fitted with 18 x 1.5mm threaded fittings.
• High tensile fixing bolt kit.
• Orange competition hook with safety catch and hand saver.
• Zinc plated for corrosion resistance.
• Heavy duty & built to last – gross weight 55kg.
• CE certified & built to ISO9001 quality management system requirements.

24v control system available on request

Industry-leading lifetime warranty on mechanical components & 3yrs warranty on electrical.
