Description

Gebuwin Worm Gear Winch – WW3000 EV capacity 3000KG

The Gebuwin worm gear hand winch has a transmission that consists of a worm shaft and wheel.

This hand winch is very safe due to the natural braking effect of the worm gear transmission in combination with the load pressure brake. In addition, the winch is easy to use, can be mounted in various ways and has a cable storage up to 120 meters.

Product specifications

robust and safe hoisting and pulling winch
in compliance with EN13157, DIN 15020 and EX types ATEX 114 (94/9/EG)
static safety factor 4
right angled, easy to grease worm transmission and maintenance free bearings
cable outlet upwards, downwards or at rear
adjustable crank, with ergonomic grip
load pressure brake with double ratchet system
zinc-plated finish (6 – 8 micron)

Technical Specs

echnical specifications	WW2000	WW2500	WW3000	WW4000	WW5000	WW7500
1st cable layer (kg)	2000	2500	3000	4000	5000	7500
Last cable layer (kg)	1038	1344	1667	2282	3276	3748
Crankforce 1st cable layer (daN)	24 (11)	28 (15)	31 (14)	30 (13)	73 (14)	78 (15)
Hoisting length by one rotation, 1st layer (mm)	12 (5)	12 (5)	11 (5)	11 (2)	13 (3)	11 (2)
Max. cable storage (m)	61	61	68	53	43	72
Diameter cable (mm)	12	12	14	16	18	22
Min. breaking force of cable (kN)	60	60	102	133	168	251
Own weight (kg)	60	60	78	80	117	190
